Can You Use UV Resin on Top Of Epoxy Resin

Resin craft enthusiasts are always on the lookout for new techniques and combinations to elevate their projects.

One intriguing question that often arises is whether UV resin can be used on top of epoxy resins. The idea of combining these two popular resin types opens up a world of possibilities for creative projects.

While both epoxy resin and UV resin share some similarities, they also have distinct characteristics. Epoxy is known for its durability and glossy finish, making it a popular choice for various applications such as resin coasters and larger projects. On the other hand, UV resin cures quickly when exposed to ultraviolet (UV) light by using a UV lamp, allowing for faster project smaller projects like jewellery and is often used for artificial fingernails.

The concept of using UV resin on top thin layers of cured epoxy offers a way to add additional layers, enhance details, or create captivating effects.

It allows resin crafters to experiment with different colors, textures, and dimensions in their projects. However, before diving into this combination, it’s important to understand the compatibility and considerations involved.

Exploring the Compatibility of UV Resin and Epoxy Resins

Understanding the properties and characteristics of UV resin

What is UV resin

UV resin, also known as ultraviolet resin or photosensitive resin, is a unique type of resin that cures rapidly when exposed to UV lights by using special a UV lamp.

It typically comes in a liquid form and is often used for small-scale, small projects, or intricate details due to its precise curing process. One of the key advantages of UV resin is its quick curing time, which can range from a few seconds to a few minutes depending on the thickness of the resin layer and the intensity of the UV lamp or UV flashlight being used.

Lets Resin UV Light

UV resin tends to have a higher viscosity compared to other resins, meaning it is thicker in consistency. This attribute is particularly beneficial for creating raised or domed effects in jewelry making or encapsulating three-dimensional objects.

The thicker consistency allows the resin to hold its shape without excessive spreading or dripping onto silicone mold, providing more control over the final result.

Another notable feature of UV resin is its excellent transparency and clarity. When properly cured, it produces a crystal-clear finish that resembles glass.

This makes it highly suitable for projects where transparency is desired, such as creating resin pendants, charms, or decorative objects. The optical clarity of UV resin allows for enhanced visual appeal and showcases the embedded elements with remarkable detail.

In addition to its curing properties, UV resin also stands out for its relatively low odor compared to other types of resin.

This can be advantageous for resin crafters who are sensitive to strong smells or prefer a more pleasant working environment.

The reduced odor makes it more comfortable to work with UV resin for extended periods of time without feeling overwhelmed by chemical fumes.

Understanding the properties and characteristics of epoxy resin

How Epoxy Resin Works

Epoxy is a versatile and widely used resin known for its durability and glossy finish. It consists of two components, resin and hardener, which need to be mixed in a specific ratio to initiate the curing process. Epoxy offers a range of properties that make it suitable for various applications and projects.

One of the notable characteristics of epoxy is its high strength.

Once fully cured, epoxy resin forms a hard and rigid surface that provides excellent resistance to impact, scratches, and general wear and tear. This makes it a preferred choice for functional and long-lasting projects such as tabletops, countertops, or resin-coated furniture.

The self-leveling nature of epoxy is another advantage that sets it apart.

It has a lower viscosity compared to UV resin, allowing it to flow more easily and evenly across a surface. This property makes epoxy resin ideal for coating larger areas or creating smooth, glossy finishes. The self-leveling ability helps minimize brush marks or unevenness, resulting in a professional-looking outcome.

Furthermore, epoxy resin offers a wide range of colors and additives, providing endless possibilities for creativity.

It can be pigmented with liquid or powder dyes, mixed with metallic or glow-in-the-dark pigments, or infused with various materials like glitter, beads, or natural elements. This versatility enables resin crafters to experiment with different effects, textures, and techniques, allowing their artistic vision to come to life.

Understanding the distinct properties and characteristics of both UV resin and epoxy is crucial when considering their compatibility for layered applications.

Advantages of Using UV Resin on Top of Epoxy Resin

LR UV 200g 2022 12 30.compressed 1600x1600

Combining UV resin with cured epoxy offers several advantages that can elevate resin craft projects to new heights. By layering UV resin on top of epoxy , crafters can add depth, dimension, and intricate details to their creations. Here are some benefits of this combination:

  1. Enhanced clarity and depth: UV resin’s exceptional transparency, when applied over epoxy, the UV resin intensifies the depth and clarity of the underlying layers. This effect is particularly striking when working with resin jewelry or decorative objects with embedded elements. The combination creates a mesmerizing visual impact that captivates the viewer.
  2. Faster curing time: UV resin cures almost instantly when exposed to ultraviolet light. By applying UV resin on top of cured epoxy, crafters can skip the lengthy curing process associated with epoxy resin alone. This saves time and allows for quicker project completion, making it especially useful for time-sensitive or production-oriented works.
  3. Versatile layering effects: UV resin’s thick viscosity allows for layering and building up multiple coats, resulting in unique visual effects. Crafters can create domed surfaces, encapsulate additional elements, or achieve a glass-like finish. The combination of UV resin and epoxy enables the creation of intricate designs with added depth and texture.

Factors to Consider When Using UV Resin Over Cured Epoxy

While combining UV resin and epoxy opens up exciting possibilities, it’s important to consider a few factors to ensure a successful outcome. Here are some key factors to watch out for:

  1. Adhesion and compatibility: Before applying UV resin over epoxy, it’s crucial to ensure proper adhesion and compatibility between the two resins. Conducting a compatibility test on a small sample is recommended to verify that the UV resin adheres well to the cured epoxy surface without any undesirable reactions or delamination.
  2. Surface preparation: Proper surface preparation is essential for a strong bond between the two resins. Ensure that the cured epoxy surface is clean, free from any contaminants or residues, and lightly sanded to promote adhesion. Creating a slightly roughened surface provides a better grip for the UV resin, increasing its durability and longevity.
  3. Thickness and curing considerations: When layering UV resin over epoxy resin, consider the thickness of each layer. Applying excessively thick layers of UV resin may result in uneven curing or excessive heat generation during the curing process, which can negatively affect the overall outcome. Follow the manufacturer’s instructions regarding layer thickness and curing times to achieve the desired results.

By taking these factors into account and understanding the benefits of using UV resin on top of cured epoxy resin, resin crafters can explore new dimensions of creativity and produce stunning pieces that showcase the best qualities of both resins.

Step-by-Step Guide: Applying UV Resin Over Epoxy Resin

Preparing the cured epoxy resin surface for UV resin application

  1. Clean the surface: Begin by thoroughly cleaning the cured epoxy resin surface. Remove any dust, debris, or oils using a lint-free cloth and a gentle cleaner. Ensure that the surface is completely dry before proceeding.
  2. Lightly sand the surface: Use fine-grit sandpaper (around 220-400 grit) to lightly sand the cured epoxy resin surface. This step helps create a slightly roughened texture, promoting better adhesion between the UV resin and the epoxy resin. After sanding, wipe away any sanding residue with a clean cloth.
  3. Degrease if necessary: If you notice any greasy or oily spots on the surface, use a mild degreaser or isopropyl alcohol to remove them. This step is crucial for ensuring a clean surface free from any contaminants that could compromise the adhesion of the UV resin.

Techniques and tips for achieving a successful bond between the two resins

  1. Apply a thin layer of UV resin: Start by applying a thin layer of UV resin onto the prepared epoxy resin surface. Use a brush or a dropper to distribute the resin evenly. Avoid applying too much resin at once, as it may result in uneven curing or excessive heat buildup.
  2. Eliminate air bubbles: To remove air bubbles trapped in the UV resin, gently pass a heat gun or a small torch over the surface in a sweeping motion. The heat will cause the bubbles to rise and pop. Be careful not to overheat the resin or hold the heat source too close to the surface, as this may cause the resin to bubble or scorch.
  3. Add desired elements or inclusions: If you wish to incorporate additional elements such as dried flowers, beads, or glitter, carefully place them on the wet UV resin layer. Make sure they are fully submerged or embedded in the resin to ensure a secure bond. Use a toothpick or a small tool to adjust the positioning if needed.

Curing process and recommended curing time

  1. Place the project under a UV light source: Once the UV resin layer is applied and any desired elements are added, place the project under a UV light source. UV nail lamps, UV curing boxes, or specialized UV resin curing lamps are commonly used for this purpose. Follow the manufacturer’s instructions regarding the distance, exposure time, and intensity of the UV light for optimal curing.
  2. Monitor the curing process: Keep a close eye on the curing process to ensure that the UV resin cures evenly and thoroughly. Rotate the project if necessary to expose all sides to the UV light. Pay attention to any instructions provided by the UV resin manufacturer regarding the recommended curing time.
  3. Allow for post-curing and final hardening: Once the initial UV curing is complete, it is recommended to allow for post-curing. This step helps ensure that the UV resin reaches its maximum hardness and stability. Post-curing times can vary, but generally, leaving the project under the UV light for an additional 24 to 48 hours is beneficial for achieving optimal results.

By following these step-by-step instructions, resin crafters can successfully apply UV resin on top of cured epoxy resin, creating stunning layered effects and enhancing the visual appeal of their projects.

Best Practices and Tips for Working with UV Resin and Epoxy Resin Together

Precautions to take when combining UV resin and epoxy resin

When combining UV resin and epoxy resin, it’s important to take certain precautions to ensure a successful outcome.

The compatibility between these two resins should be tested before applying UV resin on top of epoxy resin, especially when working on larger projects.

Conducting a compatibility test on a small sample allows you to observe how the resins bond and whether any adverse reactions occur. This step is crucial for avoiding potential issues that may arise during the curing process.

Additionally, it’s important to consider the thickness of the resin layers. Applying excessively thick layers of UV resin can lead to uneven curing, excessive heat generation, or even warping of the project. To ensure proper curing and overall project success, it’s recommended to follow the manufacturer’s guidelines for the recommended layer thickness.

This helps maintain the integrity and stability of the resin layers.

Enhancing the appearance and durability of the final project

To elevate the appearance and enhance the durability of your resin project, there are a few key techniques to employ.

Once the UV resin layer has completely cured, consider sanding and polishing the surface to achieve a smooth and glossy finish. Start with a coarser grit sandpaper and gradually progress to finer grits to achieve the desired smoothness.

Use polishing compounds specifically designed for resin to further enhance the shine and clarity of the surface. This process not only improves the overall appearance but also brings out the inherent beauty of the layered resins.

In addition to aesthetics, it’s important to protect the final project from potential UV-related damage.

UV resin, in particular, may be susceptible to yellowing or discoloration when exposed to prolonged direct sunlight or UV radiation.

To safeguard against this, consider applying a UV-resistant topcoat or a layer of clear UV-protective glassy finish resin. These protective layers act as barriers, shielding the underlying resins from the harmful effects of UV rays and preserving their clarity over time.

Common mistakes to avoid when using UV resin on top of epoxy resin

To ensure a successful outcome when working with UV resin on top of a cured epoxy resin piece, it’s important to be aware of common mistakes and take steps to avoid them.

One common mistake is insufficient surface preparation.

Power Snding Resin

Failing to properly clean, sand, and degrease the cured epoxy resin surface can result in poor adhesion between the resins. Take the time to thoroughly clean the surface, lightly sand it to create a roughened texture for better adhesion, and remove any greasy or oily spots before applying the UV resin layer.

Another mistake to avoid is rushing the cure process.

Proper cure time is essential for achieving the desired hardness, durability, and stability of the final project. Follow the recommended cure processes provided by the manufacturers.

This includes exposing the project to sufficient UV light for the prescribed amount of time and allowing for proper maintenance post-cure, which may involve leaving the project under the UV light for an extended period.

Rushing the process or skipping crucial steps can result in soft, tacky, or under-set resin.

Lastly, be mindful of the amount of UV resin applied at once. Applying thick layers of UV resin can lead to improper curing, excessive heat generation, or the entrapment of air bubbles.

It’s best to pour thin layers of UV resin, allowing each layer to cure properly before adding more resin. This approach promotes better curing, minimizes the risk of issues, and ensures a more successful outcome.


In conclusion, we have explored the compatibility, advantages, considerations, and best practices of using UV resin on top of epoxy resin.

We’ve learned that UV resin and epoxy resin can be successfully combined to create unique and stunning resin projects. By understanding the properties and characteristics of each resin, we can make informed decisions and achieve the desired results.

Throughout this article, we discussed the benefits of combining UV resin and epoxy resin, such as the ability to add layers, create depth, and enhance the overall visual appeal of your projects. We also explored important factors to consider, including proper surface preparation, layer thickness, and cure techniques.

Remember to take necessary precautions, conduct compatibility tests, and follow the recommended guidelines provided by the manufacturers.

By doing so, you can ensure successful adhesion, durability, and aesthetic results.

Now that you have a solid understanding of working with UV resin on top of epoxy resin, it’s time to let your creativity soar.

Explore the endless possibilities this combination offers and experiment with different techniques and designs. Whether you’re a seasoned, resin crafting enthusiast or a beginner, combining these resins opens up a world of exciting opportunities for your resin crafts.

Embrace the versatility and beauty of UV resin and epoxy resin together, and unlock your full creative potential.
